Need some advice on screws to mount seat rails and rail support to floor.
MY72. A picture of an all original car would be nice.
best would be detail of head and brand.
seat rail screws 72
Moderators: hot66, impmad2000, Barry, Viv_Surby, Derek, Mike Usiskin
-
jwhillracer
- Me and DDK sitting in a tree! KISSING
- Posts: 2907
- Joined: Fri Apr 18, 2008 5:58 pm
- Location: Sunny Somerset, just above the water....
Re: seat rail screws 72
My MY72 isn't exactly all original,
but I think this is one of the original seat rail mounting bolts. M6 x 15mm socket cap with a shallow head, 4mm deep. Unfortunately the original 50 years of "patina" have obscured any details that may have been there from new ..........
Hope this helps,
JW
but I think this is one of the original seat rail mounting bolts. M6 x 15mm socket cap with a shallow head, 4mm deep. Unfortunately the original 50 years of "patina" have obscured any details that may have been there from new ..........Hope this helps,
JW
Life's a single timed run with no practice....
1963 Porsche 109 Junior
1970 914/6 2.4E/Webers
1970 VW Beetle project
1972 911 Hillclimber part of the family for 40 years!
2006 Hymer Merc Starline 630
2000 T4 Van LPG
2000 Golf V5 Estate GT
1963 Porsche 109 Junior
1970 914/6 2.4E/Webers
1970 VW Beetle project
1972 911 Hillclimber part of the family for 40 years!
2006 Hymer Merc Starline 630
2000 T4 Van LPG
2000 Golf V5 Estate GT
-
dirk07
- DDK above all
- Posts: 182
- Joined: Mon Sep 11, 2017 6:08 pm
Re: seat rail screws 72
JW
Is it a shoulder screw or straight?
RIBE 8.8 or 10.9 visible on the head?
Allen size 4 or 5?
BR
Dirk
Is it a shoulder screw or straight?
RIBE 8.8 or 10.9 visible on the head?
Allen size 4 or 5?
BR
Dirk
-
Ralph
- DDK 1st, 2nd and 3rd for me!
- Posts: 2070
- Joined: Mon Feb 06, 2006 9:09 pm
- Location: Coulsdon, Surrey.
Re: seat rail screws 72
I bought a box of 200 of these low head socket cap screws a few years ago - I'll see if I can find them in the shed.
-
jwhillracer
- Me and DDK sitting in a tree! KISSING
- Posts: 2907
- Joined: Fri Apr 18, 2008 5:58 pm
- Location: Sunny Somerset, just above the water....
Re: seat rail screws 72
dirk07 wrote:JW
Is it a shoulder screw or straight? Straight M6 set screw
RIBE 8.8 or 10.9 visible on the head? No visible markings. Unlikely to be more than 8.8
Allen size 4 or 5? 5
BR
Dirk
Life's a single timed run with no practice....
1963 Porsche 109 Junior
1970 914/6 2.4E/Webers
1970 VW Beetle project
1972 911 Hillclimber part of the family for 40 years!
2006 Hymer Merc Starline 630
2000 T4 Van LPG
2000 Golf V5 Estate GT
1963 Porsche 109 Junior
1970 914/6 2.4E/Webers
1970 VW Beetle project
1972 911 Hillclimber part of the family for 40 years!
2006 Hymer Merc Starline 630
2000 T4 Van LPG
2000 Golf V5 Estate GT
-
911hillclimber
- Nurse, I think I need some assistance
- Posts: 20721
- Joined: Mon Mar 10, 2008 6:26 pm
- Location: West Midlands
Re: seat rail screws 72
I have a February build 1973 T coupe.
The screws are as JW describes, but my screws have markings, reading RIBt and 2 other letters opposite them.
These markings are on the top face of the head.
The screws are as JW describes, but my screws have markings, reading RIBt and 2 other letters opposite them.
These markings are on the top face of the head.
73T 911 Coupe, road/hillclimber 3.2L
Lola t 492 / 3.2 hillclimb racer
Boxster 987 Gen II 2.9
Lola t 492 / 3.2 hillclimb racer
Boxster 987 Gen II 2.9
-
Ralph
- DDK 1st, 2nd and 3rd for me!
- Posts: 2070
- Joined: Mon Feb 06, 2006 9:09 pm
- Location: Coulsdon, Surrey.
Re: seat rail screws 72
If you (or anyone else) wants something that is very nearly correct I have these M6 x 16 low head socket cap screws with a 5mm hex recess and 10.9 head markings on the head circumference:
Let me know if you want me to pop some in the post?
Let me know if you want me to pop some in the post?
